Laserliner 033.70A RangeXtender M 50 Laser Receiver

Laserliner 033.70A RangeXtender M 50 Laser Receiver

£92.42

SKU: SKUMO3ZA4 Categories: Electrical, Equipment, Testing Equipment Tag: Laserliner Brand: Laserliner

Description
Reviews (0)

Product Description

This laser receiver facilitates very fast alignment work over close or long ranges and is suitable for all green line lasers with GRX-READY technology. It quickly detects pulsating, high-frequency laser lines up to a maximum distance of 50 metres. The arrow symbol and millimetre display provide users with the exact height difference between the laser beam and the marking level. The measured value can be quickly and easily read from the large LC displays on both sides of the receiver. The display on the rear of the device allows the user to work in the opposite direction to the laser beam’s direction of emission and read the measured values. Supplied with universal mount, batteries and a carrying case.

For all green line lasers with GRX-Ready technology

Allows time-saving, close and long range alignment work

Millimetre display for quick and accurate reading of height differences with respect to the laser level

GRX-Ready: laser lines pulsate at a high frequency

Detects laser lines in a range of up to 50 m

Two LC displays allow the user to work in the ‘opposite’ direction to the laser, such as when fitting suspended ceilings

Head and side magnets allow quick attachment to metallic surfaces

Easily fixed to measuring staff with universal holder

Two vials for precise alignment

Supplied with universal mount, batteries and a carrying case

1 x Laserliner 033.70A RangeXtender M 50 Laser Receiver
1 x Universal mount
1 x Batteries
1 x Carrying case

Specifications

Battery operation	Yes
Laser Reception Range	max. 50 m
Power Supply	2 x 1.5V LR03 (AAA)
Operating Time	approx. 20 hours
Operating Conditions	-10°C … 40°C
Storage Conditions	-20°C … 70°C
Dimensions (W x H x D)	80 mm x 149 mm x 25 mm
Weight	400g
